MFS20

Portable Series
MFS20

Boasting the honor of the lightest weight outboard in its class, Tohatsu’s newly designed MFS 20hp Electronic Fuel Injection (EFI) is a great choice for a wide variety of boaters. Just because it is lighter in weight than our previous 20hp four stroke, doesn’t mean this model won’t deliver the same level of performance. This 20hp battery-less electronic fuel injection four stroke has exceptional torque and top end speed, with low vibration. We chose to build an EFI outboard because it has easy startup with no choke required and smooth, crisp acceleration throughout all RPM ranges. Another added benefit of an EFI versus our previous carbureted outboard is the fuel efficiency at wide open throttle, which allows you to go up to 50% farther on less fuel.

Also available on many models is the Power Tilt feature. The 20 hp Power Tilt is ideal for inflatable, fishing, and pontoon boats. The uniquely designed engine improves functionality and convenience with its light power tilt and transom bracket. Now you can tilt your motor out of the water with just a push of a button. Simplify your boating experience with a power tilt model. Try our new 20hp EFI for the ultimate boating experience because you don’t deserve anything less.



Engine 4 Stroke 2 Cylinder
Output 20 hp (14.7 kw)
Displacement 333 cc (20.32 cu.in.)
Bore x Stroke 61 x 57 mm (2.40 x 2.24 in)
Max. RPM Range 5,400 – 6,100
Starting Electric & Manual or Manual
Control Type Remote Control or Tiller Handle
Gear Shift Forward – Neutral – Reverse
Gear Ratio 2.15:1
Propeller Selection Range 6″ – 11.5″
Transom Height 15″, 20″
Fuel Unleaded Gasoline (87 Octane)
Oil Type NMMA Certified FC-W® 4-stroke oil** SAE 10W-30/40 (SF, SG, SH, SJ)
Oil Capacity 1L (1.06 qt.)
Fuel Tank 12 L (3.1 US Gal.) Separate Fuel Tank
Weight* 43 kg (94.8 lbs.)
Alternator Output Optional: 12V, 145W, 12A (Standard on Electric Start Models)
Digital ECU Controlled Ignition System Standard
Electronic Fuel Injection Standard
Start In Gear Protection Standard
Thermostat Controlled Cooling System Standard
Through-The-Prop Exhaust Standard
Oil Pressure Warning Standard
Shallow Water Drive Standard
Power Tilt Option
* Weight specification is based on the lightest version.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.
Dimensions MFS20
Model Shaft Length Cylinders Electric Start Tiller Handle Remote Control 12V Charging
System
Power Tilt Remote Fuel Tank Propeller
MFS20ES 15″ 2 S S S
MFS20EL 20″ 2 S S S
MFS20EEFS 15″ 2 S S S S S
MFS20EEFL 20″ 2 S S S S S
MFS20EEPS 15″ 2 S S S S S
MFS20EEPL 20″ 2 S S S S S
MFS20EEFTS 15″ 2 S S S S S S
MFS20EEFTL 20″ 2 S S S S S S
MFS20EEPTS 15″ 2 S S S S S S
MFS20EEPTL 20″ 2 S S S S S S
S:Standard

Specifications subject to change without notice. Additional models and/or configurations may be available. Contact your local dealer for details.
